LYD 8

LYD 8

Regular price $ 799

📦 Ships same day when ordered by 2pm PST. 🛍 Local pickup available daily. Contact us for more information. 💙

LYD 8

The biggest 2-way monitor in the LYD series. LYD 8 is a redefinition of Dynaudio's previous professional monitors. A redefinition that helps you define your artistic expression.

  • Nearfield Monitor with 8" Woofer
  • Bi-amped speaker design with 50W HF/80W LF and state-of-the-art Class-D amplification

  • Bass extension to extend or curtail the low end frequency response
  • Two different tunings: one for free standing and one designed for speakers within 50 cm of wall
  • Sound balance to influence the overall response of the speaker
  • Made in Denmark

Introduction

The LYD series is a redefinition of Dynaudio's previous professional products, and LYD 8 is the biggest 2-way version of them all. With its 8" MSP woofer and advanced DSP, the LYD 8 provides outstanding performance and a low-end precision you won't believe. Perfect for smaller studios and home setups.

A ferrit magnet system with vented pole piece for accurate driver control. Large diameter voice coil surrounds the magnet for superior linearity. The aluminium voice coil and wire are low mass so its transient response is quick and accurate. To ensure the ideal mix between stiffness, weight, and dampening for unrivalled accuracy, we mould the diaphragm and dust cap in one piece with our proprietary Magnesium Silicate Polymer.

Features

  • Nearfield monitor with 8'' woofer and 1" tweeter
  • Max. SPL (1m, pair): 112dB
  • Crossover freq.: 3900 Hz
  • Freq. Response of 45Hz - 21kHz
  • HF 50W/LF 80W Class-D amplification
  • Bass Extension
  • Position switch
  • Sound Balance

Technical Specifications

Frequency Response -6dB limits:
45 Hz - 21 kHz
Max SPL (1m, pair):
112dB
Principle:
Bass reflex
Crossover Freq.:
3900 Hz
Tweeter:
28 mm Soft dome (1.10 inches)
Woofer:
8 inches
Amplifier:
HF 50W/LF 80W Class-D
Dimensions (W x H x D):
234 x 369 x 328 mm (9.21 x 15.53 x 12.91 inches)
Weight:
10.2 kg (22.5 pounds)
I/O Connectors:
XLR Balanced: RCA Unbalanced

Downloads

Manual

Data Sheet
